Wentin Fasteners

Hex Head Metric Set Screw BZP 8.8 grade DIN933

From £0.01 inc VAT
In Stock
2 Reviews

Product Code: Z0318M


Add To Basket

Please correct the errors and try again.
:
*
:
*
:
*

Quantity Saving
10 13.23%
50 51.35%
100 56.28%

Need a bespoke quote?

Need to buy a large amount or have a large order?

Get A Quote

Product Description

Hex Head High Tensile | Metric Set Bolts | Zinc Plated | 8.8 Grade | DIN933 Explore our massive range of High Tensile 8.8 Grade set bolts in zinc plated with a vast amount of different sizes at a competitive price. Simply click the drop down menus to explore the sizes we carry in stock .

Please note: The length of the bolt is measured from underneath the head, if you would like correct measurements for any size please contact us by Email or Phone.

Spanner Sizes for each diameter:

M3
5.5MM
M4
7MM
M5
8MM
M6
10MM
M7
11MM
M8
13MM
M10
17MM
M12
19MM
M14
22MM
M16
24MM
M18
27MM
M20
30MM
M24
36MM
M30
46MM
M36
55MM



NOM DIA (MM) PITCH (MM) TAPPING DRILL SIZE (MM) CLEARANCE DRILL SIZE (MM)
M1 0.25 0.75 1.05
M2 0.40 1.60 2.05
M3 0.50 2.50 3.10
M4 0.70 3.30 4.10
M5 0.80 4.20 5.10
M6 1.00 5.00 6.10
M7 1.00 6.00 7.20
M8 1.25 6.80 8.20
M9 1.25 7.80 9.20
M10 1.50 8.50 10.20
M12 1.75 10.20 12.20
M14 2.00 12.00 14.25
M16 2.00 14.00 16.25
M18 2.50 15.50 18.25
M20 2.50 17.50 20.25
M22 2.50 19.50 22.25
M24 3.00 21.00 24.25
M27 3.00 24.00 27.25
M30 3.50 26.50 30.50
M33 3.50 29.50 33.40
M36 4.00 32.00 36.50
M39 4.00 35.00 39.50
M42 4.50 37.50 42.50
M45 4.50 40.50 45.50
M48 5.00 43.00 48.50
M52 5.00 48.00 53.00
M56 5.50 47.00 57.00
